It is imperative to maintain the rear brake pads of a VW Golf MK7. Thus, it is significant for safety and performance. Worn-out brake pads can lead to longer distances when stopping, strange noises, and sometimes even damages to other parts of the braking system. Changing them is a technique that helps save money, along with getting a better sensation about one’s car’s health. This guide takes you throughout with everything required-from preparation to finishing touches for Volkswagen brake pads replacement so that you can confidently and safely replace your rear brake pads.
Preparing To Replace The Rear Brake Pads Of A VW Golf MK
Before we get into this, it pays to put our things in order and understand what we are really talking about. The rear brake of a Golf MK7 has an electronic parking brake system, meaning the steps differ somewhat from the traditional braking system.
Tools & Material Required
Tools and materials that should be on your checklist while changing the VW Golf MK7 rear brake pads include:
- Jack and jack stands: So, that the car can be lifted and supported properly.
- Wheel chocks: To keep the car in place.
- Socket set and ratchet: Most common sizes are 13mm and 17mm.
- Torx or triple square sockets: For caliper bracket bolts (normally an M14 triple square is required).
- Allen key or hex wrench: For caliper bolts.
- Brake pad spreader or suitable pry tool: For pushing back the caliper piston.
- Rear brake pads: Ensure you get the correct ones for the VW Golf MK7 rear brakes.
- Brake cleaner: To clean rotors and caliper parts.
- High-temperature brake grease: To use on backing plates and contact points.
- Disposable gloves: To keep your hands clean.
- Diagnostic tool (VCDS or OBDEleven): To retract the electronic parking brake caliper motors before removal.
Having everything ready to go will keep the process flowing smoothly.
Safety Precautions & Vehicle Setup
Safety should be given the top Priority; before you start:
- Set the car on level surface, and engage the parking brake on.
- Place wheel chocks under the front wheels to prevent rolling of the car.
- Raise the back of the car by using a jack, and then place it on sturdy jack stands.
- Carefully remove the rear wheels.
- Avoid working on soft ground or on gradients to avert accidents.
Understanding The Rear Brake System Of VW Golf MK7
The rear brake system of the VW Golf MK7 is made up of a disc brake and an Electronic Parking Brake (EPB). This means that in the rear, there is a small electric motor in the brake calipers which forces the piston out to lock the wheels. You need to retract the piston with a diagnostic tool or through a specific service mode before changing pads; otherwise, you will damage the motor.
Also, for more informative guide, see our blog on How To Know Car Brake Pads Needs Replacing
Guide To Replacing Rear Brake Pads Of VW Golf MK7 In A Step-By-Step Manner
Removing Rear Wheels to Access Brake Pads
- Loosen the wheel nuts while still on the ground, using a lug wrench.
- Lift the rear of the car and fit jack stands.
- Remove all the wheel nuts, and then take the wheels away.
- Now you will be able to see the rear brake discs with their calipers.
Taking Off Old Brake Pads & Inspection Of Components
- Use a diagnostic-scanner (VCDS or OBDEleven) to put the electronic parking brake
calipers in service mode-for retraction of the piston to assist with removal.
- The bolts-locking the caliper to the carrier-have to be removed.
- The caliper must be pulled further away from the wheel hub and rotor, ensuring that
the brake hose is not stretched.
- The old brake pads are now to be removed from the caliper bracket.
- Check for grooves or heavy wear on the rotor. If damage is evident, consider resurfacing or replacing the rotor.
- The caliper must be inspected for external leaks or damage.
- Anti-rattle clips must be examined too; replace if necessary.
Installing New Rear Brake Pads
- Use brake cleaner to clean the caliper bracket and contact points.
- Apply a thin coat of high-temperature brake grease on the back of new brake pads and on any contact points where pads touch the bracket.
- Insert the new pads in correct order with the caliper bracket.
- If it is not already done, fully retract the caliper piston with the help of the diagnostic tool.
- Carefully mount the caliper over the new pads and rotor.
- Tighten the caliper bolts to proper manufacturer specifications.
Reassembling & Testing The Brake System
- Reinstall the rear wheels and hand-tighten the lug nuts.
- Lower the vehicle gently and then correctly torque all lug nuts in a star pattern.
- Release the vehicle from the jack stands.
- With the diagnostics tool, take the parking brake out of service mode; if needed, perform a reset.
- A few times, pump the brake pedal before driving to get the pads in contact with the rotors.
- The parking brake function should operate smoothly.
- Test drive to check that everything is normal with the brakes.
Post Replacement Tips For Volkswagen Golf MK7 Brakes
Correct Bedding-In Procedure For New Brake Pads
New brake pads are usually subjected to a bedding-in procedure where they adapt themselves, become effective, and last longer. Some of these are:
- Moderate stops-from about 25-30 mph so as to gradually heat the pads.
- No full stops during this period to avoid uneven pad deposits.
- Cooling down of the brakes afterward for proper bedding-in.
It eliminates noise and facilitates maximum braking power.
Regular Inspection And Service Tips
- Examine brake pads for wear every 10,000 km.
- Listen and keep track of any squeals or grinding noises.
- Look at the brake fluid level and top it if necessary.
- Check the rotors regularly for warping or deep grooves.
Good maintenance keeps you safe over time and saves money. For more , check-out brake repair tips
When To Seek Professional Help
At times, the task requires the use of professional tools or experience:
- Without the diagnostic tool, you won’t retract the EPB caliper motors safely.
- Saw leaking brake fluid or calipers damaged.
- Whenever one feels uneasy and is not certain about working on brakes.
Trusted mechanics can do these jobs safely and soundly. Also, see Top 5 Signs You Need A Car Brake Pads Replacement
VW Golf MK7 involves a peculiar process while changing rear brake pads; it includes electronic parking brakes, and adopting the right way will help ensure that the brakes remain properly working and safe.
The changing of back brake pads is not a simulation of cost-saving, because it’s an investment in the safety and performance of a car. Intelligent preparation, considering the EPB system’s very valuable role, and following the step-by-step instructions will help you get the job done confidently. When in doubt, however, professional service will give you peace of mind on the road.
